Used Equipments

Used Equipments



Yard loaders

Series 2000/3000/4000

This series has been specially conceived and designed for use in agriculture, landscape gardening, municipal services and building work.  This combination of maximum possible performance, compact dimensions, safety and comfort is only to be found in Schäffer machines. You too should profit from our experience of over 50 years in the building of loading vehicles.

Modell Output Working weight Lifting power Tipping load
2020 15 kW (20 HP) 1400 kg 1200 kg 750 kg
2022 16 kW (22 HP) 1500 kg 1500 kg 890 kg
2024 S
19 kW (26 HP) 1650 kg 1500 kg 900 kg
2026 /
2026 S
19 kW (26 HP) /
24 kW (33 HP)
1750 kg 1500 kg 920 kg
2033 /
2033 S
24 kW (33 HP) /
26,5 kW (36 HP)
2080 kg 1600 kg 1000 kg
3033 /
3033 S
24 kW (33 HP) /
33 kW (45 HP)
2270 kg 1600 kg 1100 kg
3036 /
3036 S
26,5 kW (36 HP) /
33 kW (45 HP)
2310 kg 1650 kg 1200 kg
3050 38 kW (50 HP) 2450 kg 1700 kg 1400 kg
3150 /
3150 S
38 kW (50 HP)
45 kW (60 PS)
2500 kg 2100 kg 1850 kg
4048 /
4048 S
36 kW (50 HP) /
45 kW (60 HP)
2920 kg 2300 kg 1800 kg
4050 Z /
4050 ZS
36 kW (50 HP) /
45 kW (60 HP)
3300 kg 2400 kg 2000 kg

Series 200/300/400

The proven yard loaders of this production series offer an impressive synthesis from functionality and power. The loading work in difficult and inaccessible places is the specialised field of application to which they are best suited. The narrowness of the machines width, only 790 mm for the model 217, guarantees a passage through small door openings and along narrow access ways. The maximum elevation height for the model 442 S is up to 3270 mm, this makes it ideal for example, when loading high feed mixers as well as many other every day agricultural tasks.

Modell Output Working weight Lifting power Tipping load
217 15 kW (20 HP) 1495 kg 900 kg 750 kg
221 S
19 kW (26 HP) 1655 kg 950 kg 780 kg
222 S
19 kW (26 HP) 1700 kg 950 kg 850 kg
326 S
24 kW (32 HP) 1970 kg 1300 kg 1000 kg
336 S
26 kW (36 HP) 2120 kg 1500 kg 1100 kg
442 S 36 kW (50 HP) 2595 kg 1800 kg 1600 kg
